乾式吹吸複合泵 - DVT系列 |
|
| |
| 乾式吹吸複合泵 - DVT 3060 |
 |
| |
| Type |
Item |
Pressure
(bar) |
50Hz Vacuum (bar) |
60Hz Vacuum (bar) |
| 0 |
-0.4 |
-0.5 |
-0.6 |
0 |
-0.4 |
-0.5 |
-0.6 |
| DVT 3060 |
Suction of rate (m/h)
Blast of rate (m/h)
Power (kW)
Temperature compressed air (°C) |
+0.4 |
56
58
1.78
40 |
29
42.7
2.1
44 |
21.8
37.4
2.17
45 |
16.6
33.9
2.18
46 |
65.1
68.4
2.41
42 |
35.2
49.7
2.71
46 |
28
44.6
2.76
46 |
21.6
39.1
2.82
46 |
Suction of rate (m/h)
Blast of rate (m/h)
Power (kW)
Temperature compressed air (°C) |
+0.5 |
55
56.8
1.87
41 |
28.3
42
2.1
44 |
22.1
37.2
2.23
45 |
16.1
32.7
2.33
46 |
65
68.2
2.52
44 |
34.7
49.5
2.86
46 |
27
43.4
2.85
46 |
21.1
38.5
2.9
47 |
Suction of rate (m/h)
Blast of rate (m/h)
Power (kW)
Temperature compressed air (°C) |
+0.6 |
54.5
56.1
1.9
40 |
28.2
41.3
2.25
44 |
21.8
37
2.35
46 |
15.5
32.3
2.41
46 |
63.7
67.1
2.6
45 |
33.7
48.2
2.91
48 |
27.2
43.3
3
49 |
20.5
38
3.05
49 |
|
| |
| Unit : mm (inch) |
| Type |
A |
B |
B1 |
D1 |
D2 |
E |
E1 |
F |
G |
G1 |
| DVT 3060 |
326 |
190 |
95 |
PF 1” |
PF 1” |
138 |
85 |
46 |
335 |
197 |
| Type |
G2 |
H |
H1 |
H2 |
H3 |
I |
K |
K1 |
K2 |
KM |
KL |
| DVT 3060 |
141 |
162 |
290 |
333.5 |
315 |
97 |
393 |
414 |
448 |
357 |
750 |
 |
|
|
| |
 |
|
